Digital peripherals

AS-i compact module K45 digital 4 DQ, IP67 4 x output, 1 A 24 V DC maximal 3 A for all outputs 4 x M12 socket Mounting plate 3RK1901-2EA00 or 3RK1901-2DA00 must be ordered separately

ASIsafe Basis Safety monitor 2 F-RO 2 enabling circuits IP20, with screw terminal removable terminals Safe output relay Response time maximum 40 ms Monitor type 2, Version 3 Can be used up to Category 4 (EN954-1) up to PL E (EN ISO 13849-1) up to SIL 3 (IEC 61508)

AS-INTERFACE !!! PHASE-OUT PRODUCT !!! FOR FURTHER INFORMATION PLEASE CONTACT OUR SALES STAFF! SAFETY AT WORK SLIMLINE S22.5F STANDARD IP20 2F-DI

AS-INTERFACE SLIMLINE MOD. S45, !!! PHASE-OUT PRODUCT !!! FOR FURTHER INFORMATION PLEASE CONTACT OUR SALES STAFF! DIGITAL,4I/4O,POTENT.-FREE,IP20 4 X 1 INPUT, 200MA, PNP 4 X 1 OUTPUT, 1A, DC 24V CAGE-CLAMP, MODULE WIDTH 45 MM

SLAVE 1: ASISAFE COMPACT MODULE K45F, IP67, DIGITAL, 4F-DI, 4 X SAFE INPUT CAT. 1/2 OR 2 X SAFE INPUT CAT. 3/4 (CAT.: SAFETY CATEGORY ACCORDING TO EN 954-1); 4 X M12 SOCKET. MODULE USES 2 AS-I ADDRESSES. MODULE IS ASSIGNED TO 2 AS-I ADDRESSES. MOUNTING PLATE 3RK19012EA00 TO BE ORDERED SEPARATELY.

AS-INTERFACE COMPACT MOD., IP67 ANALOG, 2AI, NUMERIC. FORMAT S7 2 X INP. (M12), PT100 LIN. ST. FOR 4-WIRE SENSORS ACTIVE CHANNELS 1 AND 2 MOUNTING PLATE 3RK19010CA00 TO BE ORDERED SEPARATELY

ACTUATOR SENSOR INTERFACE 4I APPLICATION MODULE 4X M12 SOCKETS, EMI

ASIsafe extended Safety monitor 2 F-RO 2 enabling circuits IP20, with screw terminal removable terminals Safe output relay Response time maximum 40 ms Monitor type 4, Version 3 Can be used up to Category 4 (EN954-1) up to PL E (EN ISO 13849-1) up to SIL 3

ASISAFE ENHANCED SAFETY MONITOR 1 F-RO, 1 ENABLING CIRCUIT, IP20, WITH SCREW-TYPE TERMINALS (REMOVABLE), SAFE OUTPUT RELAY RESPONSE TIME MAX. 40 MS, MONITOR TYPE 3, VERSION 3, APPLICABLE UP TO CATEGORY 4 (EN 954-1), UP TO PL E (EN ISO 13849-1), UP TO SIL 3 (IEC 61508), FOR AS-INTERFACE / AS-I SAFETY AT WORK

AS-INTERFACE COMPACT MOD. K45, IP67, DIGITAL, 4 INPUTS 4 X 1 INPUT, 200MA MAX., PNP 4 X M12 SOCKET

AS-i compact module K60 digital 8 DI, IP67 8 x inputs, maximum 200 mA 8 x M12 socket Y-II assignment Mounting plate 3RK1901-0CA00 must be ordered separately

ACTUATOR SENSOR INTERFACE 4AR APPLICATION MODULE 4X1 OUTPUT RELAYS DC 24V, 1A EXTERNAL VOLTAGE SUPPLY VIA M12 4X M12 SOCKETS, EMI

ACTUATOR SENSOR INTERFACE F90 4I/40 APPLICATION MODULE, IP20 4X1 INPUT 200MA PNP,4X1 OUTPUT ELECTRONICS DC 24V, 1A SCREW TERMINALS, EXT. VOLTAGE SUPPLY VIA SCREW TERMINALS

AS-INTERFACE FK-INTERFACE MODULE FOR AS-I LINE (YELLOW) AND AS-I POWER CABLE (BLACK), EEMI

AUXILIARY SWITCH BLOCK, 22 (2NO+2NC), DIN EN50012, 4-POLE, SCREW CONNECTION, FOR MOTOR CONTACTORS, SIZE S0...S3

SIMATIC DP, ELECTRONIC MODULE FOR ET 200S, 4SI SIRIUS, 4 POINT-TO-POINT INTERFACES 15MM WIDTH, IO-LINK MASTER FOR SIRIUS SWITCHGEAR

AS-INTERF. COMP. MOD. IP67 DIGITAL, 4O, 4 X 1 OUT.,ELECTR., 2A, 24 V DC 4 X M12-STANDARD-SOCKET FOR CONNECTING OUTPUTS MOUNTING PLATE 3RK19010CA0 TO BE ORDERED SEPARATELY

AS-INTERFA. COMPACT MODULE K60, DIGITAL, 4I, IP67, 4 X 1 INPUT, MAX. 200MA, PNP, 4 X M12 STANDARD SOCKET Y-II-ASSIGNMENT ATEX EX II 3D T60 C IP65X OBSERVE SPECIAL CONDITIONS FOR SAFE OPERATION: SUITABLE MEASURES TO PREV. MECHA. DAMAGE REQUIRED. FOR DETAILS SEE OPER. INSTRUC. MOUNTING PLATE 3RK19010CA00 TO BE ORDERED SEPARATELY
