Digital peripherals

X20 Digital Output Module, 8 Outputs, 24 VDC, 0.5 A, Source, 1-Wire Technology

X20 Safe digital input module, 4 safe digital inputs type A, input filter configurable, 4 pulse outputs, 24 VDC

X20 Digital counter module, 1 SSI absolute encoder, 5 V, 1 Mbit/s, 32 bits

8 digital outputs with 2 A Source connection 1-wire connections Power feed integrated in the module Integrated output protection This module is equipped with 8 outputs for 1-wire connections. The outputs are designed for a source circuit. The nominal output current is 2 A. The output supply is fed directly to the module. An additional supply module is not needed. There is no connection between the module and the I/O supply potential on the bus module.

2 inputs for resistance temperature measurement For PT100 and PT1000 Configurable sensor type per channel Direct resistance measurement Configurable 2- or 3- wire connections per module Configurable filter time The module is equipped with 2 inputs for PT100/PT1000 resistance temperature measurement. This module is designed for X20 6-pin terminal blocks. If needed (e.g. for logistical reasons), the 12-pin terminal block can also be used.

12 digital outputs Source connection 1-wire connections Integrated output protection This module is equipped with 12 outputs for 1-wire connections. The outputs are designed for a source circuit.

12 digital inputs Sink connection 1-wire connections Software input filter can be configured for entire module The module is equipped with 12 inputs for 1-wire connections. The module is designed for sink input wiring.
